Oil Supply Diagram V-6
1.Oil tank assembly
2.Oil pick-up
3.Oil supply hose
4.In-line oil filter
5.Oil injector assembly
6.Oil distribution hoses
7.Oil pressure sensor
8.Rear oil manifold
Service Manual 115-200 HP E-TEC Oiling System [Oil Supply Diagrams - V6]
